SmallHD DP7 Monitor

The SmallHD DP7-Pro LCD monitor offered by Lightbulb Rentals is a robust and feature-rich tool designed for professional video monitoring. Here’s a detailed overview of its capabilities and features:
SmallHD DP7-Pro LCD Monitor Features:
Display Specifications:
7″ IPS LCD Display: Provides a high-quality viewing experience with a resolution of 1280 x 800 pixels.
Color Depth: Supports 8-bit color depth for accurate color representation.
Contrast Ratio: Offers an 800:1 contrast ratio for clear differentiation between light and dark areas.
Construction and Durability:
Reinforced Aluminum Housing: Built with a milled aluminum housing that is extremely durable, capable of withstanding heavy pressure.
Lightweight: Despite its durability, the monitor is lightweight, weighing only 1.2 lbs, making it easy to handle on set.
Connectivity Options:
Input and Output: Features HD-SDI and HDMI inputs and outputs for versatile connectivity.
Hirose Input: Supports an optional SmallHD Component/Composite breakout cable via a Hirose input.
Advanced Monitoring Capabilities:
3D LUT Support: Offers flexible 3D LUT support, allowing for the application and preview of LUTs during monitoring. LUTs can be uploaded via SD card transfer and organized into custom folders.
Monitoring Tools: Includes a comprehensive set of monitoring tools such as scopes (likely waveform, vectorscope, etc.), enabling precise image analysis.
Hot Key Interface:
Multi Hot Key Interface: Utilizes a multi hot key interface with 24 assignable hot keys that appear on the screen when triggered by proximity sensors near the front panel buttons.
User Interface: Features a scroll wheel on each top corner for navigation and selection of features and hot keys, which can be particularly useful with sunshades that obstruct front panel buttons.
Lockable UI: The user interface can be locked via a physical switch to prevent accidental changes during critical production moments.
Operational Flexibility:
Simultaneous Input and Output: Both SDI and HDMI inputs are simultaneously active, allowing toggling between two live signals. The monitor automatically converts the input signal for output via either of the outputs.
Practical Applications:
On-Set Use: Ideal for use on set where accurate monitoring and LUT application are crucial for evaluating image quality, making lighting adjustments, and for client or director reviews.
The SmallHD DP7-Pro LCD monitor combines durability, advanced monitoring features, and intuitive controls to meet the demands of professional video production environments, providing reliable performance and flexibility in monitoring workflows.
