Teradek Bolt 3000 Receiver
Camera Accessories

Teradek Bolt 3000 Receiver

$200 /day
What’s included
  • (5) Teradek Antenna
  • (2) Short SDI
  • (2) 2-Pin LEMO to D-Tap Cable
  • AC to 2-Pin LEMO Adapter (No C7)
About this rental

This is the receiver side of the Teradek Bolt 3000 wireless video system, taking the zero-delay HD feed from a camera-mounted Bolt transmitter at up to about 3000 feet and outputting it to a monitor or video village. It gives the director and crew a clean, real-time image with no cable run, and pairs with Bolt 3000 and compatible Bolt transmitters.

Lightbulb rents the Teradek Bolt 3000 Receiver along with thousands of other items with next-day pickup or regional delivery across New York and Pennsylvania. Every order is fully inspected and prepped before it ships, and our team can help you build a matching package, add expendables, or answer technical questions before your shoot.

Specifications
Range
up to 3,000 ft (914 m) line-of-sight
Latency
<1 ms (zero delay)
Frequency band
5 GHz
Max resolution
1080p60
Color
SDI 10-bit 4:2:2; HDMI 8-bit 4:4:4
Audio
24-bit 48 kHz PCM embedded
Encryption
AES-128
Receivers
multicast up to 4 per transmitter
Software (RX)
3D LUT engine, 5GHz spectrum analyzer (Bolt Manager)
Backward compatible
Bolt 3000, Sidekick II, 703 Bolt
Construction
milled aluminum chassis
Video outputs (RX)
dual 3G-SDI + HDMI (cross-conversion)
Power
2-pin DC + integrated pass-through battery plate (V/Gold-Mount)
Antennas
5 external
Mounting
integrated NATO rail + 3/8"-16 (ARRI-compatible)
Output Formats
Up to 1080p60 (3G-SDI + HDMI)
